Endoscopic closure of a radiation induced colovesical fistula using the novel over-the-scope Padlock Clip system—a case report

Introduction

Colovesical fistulas (CVFs) are known complications of complicated diverticular disease, malignancy, and Crohn’s colitis (1). With the increasing use of radiation therapy in relation to pelvic malignancies, we now have a rising incidence of benign radiation induced CVF that could potentially lead to recurrent bouts of cystitis, pyelonephritis, renal abscesses, renal impairment and systemic infection resulting from ongoing fecal contamination through the abnormal connection (2). The complications of urosepsis, in particular, carry high morbidity and mortality, and thus CVF should generally be an indication for surgical repair to avoid these problems (3). Unfortunately, not all patients are fit enough for operative management. As a consequence, they are managed conservatively despite the fact that spontaneous closure only occurs about 2% of the time (4,5).

Recently, with the advancement of endoscopic techniques, we are now able to venture into the prospect of endoscopic closure for intestinal fistulas. This would undoubtedly address patients who are unfit for operative intervention and might emerge as a complementary treatment option in the future.

We present a case of a patient who was successfully managed with endoscopic closure using the Padlock Clip Defect Closure System (STERIS). We present the following article in accordance with the CARE reporting checklist (available at https://asj.amegroups.com/article/view/10.21037/asj-21-6/rc).

Case presentation

Our patient was a 68-year-old lady who presented with one week history of high-grade fever, lower abdominal pain and hematuria in addition to pneumaturia and fecaluria. Her background comorbidities included hypertension, Type II diabetes mellitus, hyperlipidemia and decompensated heart failure. In addition to this, there was also a history of cervical cancer diagnosed 12 years ago for which she successfully underwent a combination of chemoradiation and brachytherapy treatment.

Clinical examination revealed a frail and cachectic lady with a blood pressure of 80/40 mmHg, pulse rate of 114 beats per minute, temperature of 39 ℃ and respiratory rate of 36 breaths per minute. Her oxygen saturation was 92% on room air and she was clinically pale and tachypneic. There was mild tenderness over at the suprapubic region. Other systems examination was unremarkable.

Relevant biochemical investigations revealed elevated total white cell count at 14.80×10³/µL [normal range (4.00–10.00)×10³/uL], hemoglobin 6.6 g/dL (normal range 12.0–15.0 g/dL), C-reactive protein 31.2 mg/L (normal <5.0 mg/L), ferritin 511.5 ng/mL (normal range 4.6–204.0 ng/mL), serum albumin 17 g/L (normal range 34–48 g/L), urea 27.3 mmol/L (normal range 3.5–7.0 mmol/L) and creatinine 108.6 µmol/L (normal range 50.4–98.1 µmol/L). In addition, her urine cultures revealed mixed isolates of Enterobacter spp and Klebsiella spp. while her blood cultures yielded no growth. Our provisional diagnosis was acute kidney injury secondary to urosepsis complicated by a possible enterovesical fistula.

Our patient subsequently underwent fluid resuscitation and was started on parenteral broad-spectrum antibiotics. She then went on to have a CT abdomen and pelvis performed and this revealed a large diverticulum seen within the left dome of the urinary bladder (Figure 1). In addition, the bladder wall was also thickened in keeping with ongoing inflammation. The suspected fistula however could not be delineated. Following this, a cystoscopy performed revealed large amount of blood clots adhered to the site of the bladder diverticulum. This was not amenable for removal and attempts to locate the fistula from the bladder was unsuccessful. Subsequently, colonoscopy performed two days later revealed a 6 mm slit-like opening located 19 cm from the anal verge within the rectosigmoid colon. To confirm that this was the colonic end of the fistula, methylene blue dye was flushed through the bladder irrigation catheter and a gush of blue dye could be clearly seen flowing into the colonic lumen (Figure 2).

Figure 1 Axial and coronal planes of CT abdomen and pelvis showing the large diverticulum (yellow arrows).

Figure 2 Colonoscopy with pre- and post-methylene blue instillation highlighting the site of the colovesical fistula. Notice the gush of blue dye flowing into the colon (white arrows).

As she was surgically unfit to undergo a timely operative intervention which was important to treat and avoid a recurring episode of urosepsis, a collective decision with the surgeon was made to attempt endoscopic closure with an over-the-scope clip (OTSC) on the colonic end of the fistula. The Padlock Clip with a tissue chamber depth of 1.0 cm was selected for this purpose. The area around the fistula was first marked with argon plasma coagulation to allow easier re-identification. Upon installation of the Padlock Clip, we re-negotiated the colonoscope back to the CVF site. Endoscopic suctioning of the marked location was then applied followed by OTSC deployment (Figure 3). The procedure was uncomplicated and deemed a success with the absence of methylene blue flush post-procedurally. A pseudopolyp marked the site of clip deployment and minor expectant bleeding tackled with snare-tip-soft-coagulation technique.

Figure 3 The colonic end of the fistula was marked with argon plasma coagulation (left) followed by OTSC deployment (right). OTSC, over-the-scope clip.

Our patient was discharged well after a week’s observation with immediate resolution of pneumaturia and fecaluria. A repeated colonoscopy eight weeks later revealed that the Padlock Clip was still intact (Figure 4). Her condition improved remarkably though she was not keen for further definitive intervention despite extensive counselling.

Figure 4 The pseudopolyp appearance following OTSC deployment during the index colonoscopy (left) and eight weeks later (right). The OTSC prongs could be seen (green arrows). OTSC, over-the-scope clip.

All procedures performed in this study were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient for publication of this case report and accompanying images. A copy of the written consent is available for review by the editorial office of this journal.

Discussion

Colovesical fistula is the most commonly encountered entity of enterovesical fistulas constituting up to approximately 70% of the overall cases (1). The etiology of CVF encompasses a heterogenous group of both benign and malignant conditions. Specifically, and in relevance to our patient, its association with chronic radiation enteritis is a well-described complication despite a low reported incidence ranging from 0.3–3.0%. Recognition of radiation enteritis as a potential side effect of radiotherapy is pertinent as this would help in making an early diagnosis through clinical presentation and subsequently assist in organizing relevant radiological and endoscopic evaluation. These group of patients should then be closely monitored and followed up for signs of radiation enteritis sequelae, namely fistula formation, strictures, perforation and abscesses (6-8).

Though the incidence of radiation induced CVF is relatively scarce, recent evidence indicates that with improved detection of pelvic cancers and increasing use of external beam radiotherapy and brachytherapy, a foreseeable increase in complex cases in the near future is expected to occur. In overcoming these complications, various strategies were employed with the primary aim of mitigating radiation enteritis with the most important being the reduction of radiation dose and field size of exposure. With reference to the specific treatment for radiation enteritis, guidelines were equally ambiguous with only endoscopic thermal coagulation and hyperbaric oxygen therapy showing some potential promises in palliating symptoms (8).

In terms of the definitive management for CVF, surgical resection of the involved bowel segment and associated fistula with subsequent re-anastomosis is the present standard of care to achieve the best outcome. This reduces the risk of recurrence and is better than relying on the low likelihood of spontaneous closure resulting from defunctioning colostomy. Depending on the patient’s age and timing of presentation, underlying co-morbidities and concurrent medical issues, surgical options may include either a one-stage repair or multiple stages of repair (1). It must however be borne in mind that these are major procedures and there are a select few who are too ill and not sufficiently fit to undergo timely surgery. Furthermore, repeated bowel resections may become justified in the future, and the inherent risk of short-bowel syndrome needs to be considered. On the flipside, subjecting them to conservative management would not be ideal either (1).

Endoscopic through-the-scope clips (TTSCs) have been used as a combined approach in CVF closure. However, the setback was that TTSC generally falls off within an average of 10 to 14 days and might not be long enough to permit fistula healing (9). Modern advancement in endoscopic accessories has led to the development of OTSC with the initial intent of securing difficult gastrointestinal bleeding. These are large clips designed to provide superior full thickness closure strength mimicking hand suture as demonstrated in ex vivo porcine model (10). In view of this, their role in endotherapeutics has since expanded to include sealing gastrointestinal perforations, resection of early colorectal cancers and closure of iatrogenic and pathological fistulas and leaks (11-13). Early reports were both encouraging and optimistic though there were limited cases with inadequate follow-up duration. To date, there were no technical failures and intraprocedural complications for all indications though the final success rates were ultimately dependent on the size and chronicity of the primary pathology (13-15).

Historically, the first OTSC system introduced was the Ovesco Clips (Ovesco Endoscopy AG, Tübingen, Germany) followed by the more recently developed Padlock Clip which offered a more affordable alternative and possibly equal success in managing gastrointestinal fistulas which had no prior intervention (16-18). Additionally, there were two reported cases of failed rectovesical and rectocutaneous fistula closure with the Ovesco clips that were subsequently managed with the Padlock Clips. The patients went on to have clinical resolution for up to 8 months despite clip detachment within 30 days suggesting that it may be a reliable option in salvage therapy as well (18).

The attractive feature of the Padlock Clip is its ease of installation and the unique circumferential 6-inner prongs which offer a strong grip and watertight closure through simple tissue suctioning and thumb press clip deployment technique (19). Despite the firm grasp and compression offered by OTSCs, their unique design does not lead to tissue ischemia or laceration which is favorable in encouraging fistula healing. Unlike Ovesco Clips, the Padlock system is less studied due to its novelty, and our case serves to illustrate its versatile role in gastrointestinal fistula closure (19). Furthermore, our Padlock clip remains attached even after 8 weeks of deployment.

An important point to note in terms of technical aspect is the selection of the ideal gastrointestinal fistulas for endoscopic closure. In general, the fistula should allow an unobtrusive view where it is easily accessible and intervention is feasible. Bearing in mind that the colonoscope fitted with a long distal attachment device would be difficult to negotiate colonic loops, the location of the fistula also plays a significant factor in determining technical success. In this regard, the ability to obtain a shortened and straight endoscope is vital to ensure the ease of maneuverability during OTSC application. The surrounding colonic mucosa should also be healthy and not friable or necrotic to encourage optimal OTSC deployment (20).

The OTSC is indeed an innovative device though more research is warranted to address its long-term efficacy, technical failures, limitations of use in terms of fistula size and complications before wider implementation. As of the present status, OTSC and in particular the Padlock Clip (as shown in our patient) can be offered as a temporizing measure following multidisciplinary discussions on a case-by-case basis until more definitive treatment could be offered.

Conclusions

The introduction of OTSCs in performing CVF closure offers a novel endoscopic approach in bridging the management gap for patients who could not undergo timely surgery while at the same time are not suitably managed conservatively. The simple installation of the Padlock Clip prior to its application, ease of use and rapid deployment are attractive features in performing endoscopic gastrointestinal fistula closure. Looking forward, endoscopic intervention for fistula closure using Padlock Clips may have a more definitive role for these heterogenous groups of pathology though larger scale studies with longer follow-ups are eagerly awaited.
